Land Rover Key Replacement Houston Texas

15-09-2021 - We would like to welcome you to OkeyDoKeyLocksmith! Have you lost or broken the key to your Land Rover? Do you want to copy transponder key, proximity fob or high security? Googling for a bargain and convenience key replacement solutions?

Good news

Okey DoKey Locksmith offer 24/7 fast and affordable Land Rover keys replacement. Call for immediate assistance, free estimate and scheduling. Our expert mobile car locksmith come to you to duplicate or replace your lost keys on-site.

Furthermore, we can solve all your Land Rover key, locks and ignition pains.

Does Land Rover use transponder keys?

The first Land Rover transponder key appeared in 2002 with the Freelander. Since 2006 all models manufactured by Land Rover use transponders.

In 2010 Land Rover first introduce Push Start ignition and smart keys in their vehicles. This system consist of the Remote Function Actuator (RFA) or Keyless Vehicle Module (KVM) ECU.

What is a Land Rover transponder key used for?

The basic purpose of Land Rover transponder key is to eliminate car theft. Without the proper programmed chip in the key, the starter solenoid will be cut-off the power to the ignition and the car will not start.

How does Land Rover immobilizer works?

Immobilized Range Rover consist of a Body Control Unit (BCU), communication channel (K bus), Electronic Control Unit (ECU) and transponder key. Range Rover use a 'rolling code' system to change value each time the key is used.

When the driver door is unlocked, the BCU outputs a 'vehicle unlocked' message on the K bus to the ECU. The ECU then energises the transponder coil around the ignition switch. When the transponder key inserted into the ignition switch, the ECU reads the identity of the chip. If the key is valid, the ECU outputs a 'valid key in ignition lock' message on the K bus which disengages the steering column lock. The steering lock then sends a release signal to the immobilisation ECU.

When the ignition switch is turned, the ECU interrogates the transponder for the password and rolling code. If these are correct, the ECU sends the coded release signal to the ECM and energises the starter solenoid to crank the engine. The ECU also update the transponder with a new rolling code to use for the next time.

Land Rover use a Stealth Active anti clone theft immobiliser system which prevent cloning of keys! The Stealth Active system runs in the background of the immobilizer. When a car thief try to use a cloned key the dash presented an unauthorised mode alarm which prevents starting the vehicle.

How do I know if I have a transponder key?

Following are the list of Land Rover models that use transponders:

• Land Rover Range Rover Sport 2006-2014
• Land Rover LR2 2005-2009
• Land Rover LR3 2005-2009
• Land Rover Range Rover 2004-2009
• Land Rover Evoque 2012-2014
• Land Rover Freelander 2002-2006
• Land Rover LR4 2010-2014

How to duplicate Land Rover keys and remotes?

Duplicating keys for a Land Rover requires both a laser key cutting machine and a special factory computer and software.

Can I duplicate Land Rover keys and remotes by myself?

Land Rover offer no onboard interface to duplicate keys by yourself. Diagnostic tools and programmers are required for any update to the ECU.

Duplicate Land Rover key by VIN

The first thing to do when duplicating the key is to cut the metal blade using the EKA code. This EKA code is provided with every new Land Rover on a vary small tin or plastic plate.

If the EKA code is lost or misplaced, it can also be obtained from the manufacturer by the VIN.

Duplicating keys by VIN is done by a locksmith or the Land Rover dealer

For this, ALL functional keys should be programmed again along with the new key. Basically, this process erased all current keys from the cars computer and then all keys are programmed again.

Two important tips before buying a duplicate Land Rover key or remote:

1. One of the main problems owners face when looking for a duplicate key is shortage of blank keys. Don't drive to the dealer before calling with the VIN to make sure they have the key in stock. If they don't have it you can ask them to order it for you which usually takes 3-5 days.
2. Prices vary slightly depent on the dealer, so for the best price you better call more than one dealership. Call a few dealerships with your VIN and ask for a quote.



Land Rover key cloning

Key cloning is a process of copying the key without having the car. Using the data embedded in the original transponder to program a new replicates key.




Land Rover was all confident in their ECU software release in stopping key cloning. Fortunately, locksmiths and unfortunately vehicle thieves are always one step ahead. Software and components are constantly design and develope in order to clone a new key to Land Rover.




A locksmith with after market key programmer and diagnosis tool like IIDtool can create cloned key using 2 methods:



1. Reading the key - scan the key to get it's data and copy it to a new blank
2. Vehicle OBD port - read the key data from the vehicle and copy to a new blank




How to program a Land Rover remote?

Sometimes after replacing a battery in the key or in the vehicle, your remote m8ight stop responding. If your remote is not working or not recognized, use the following simple steps to get it working again:

1. Step outside of the vehicle with all of doors closed.
2. Continuously press down the “Lock” button and put the key in your driver’s door lock.
3. Rotate the key in the door lock clockwise as far as possible for three seconds.
4. Rotate the key back to the center position and rem ove it without releasing the “Lock” button.
5. Release the “Lock” button on the remote to synchronize it with the vehicle.

Lost/stolen key replacement! What to do?

When you lose all your keys to a Land Rover the process special reprogramming tools are required. This are available only to the Land Rover dealer or to a licensed locksmith.




You will need the vehicle identification number to place order (VIN) and provide valid proof of ownership with a picture ID. If you choose the dealer, many times keys will arrive at dealership from the manufacturer within 2-3 business days. The vehicle computer is reprogrammed to accept a new key and reject the lost keys. Vehicle must be present at the dealership or having a mobile locksmith onsite.




My Land Rover ignition key wont turn! What to do?

There are many reasons for ignition problems! Please check our article about ignition repair and replacement.




How much is a replacement Land Rover key?




Service	Price
Car Lockout	$60-$120
Locked keys in trunk	$70-$195
Door lock rekey/repair/change	$200-$295
Lost key replacement	$195-$370
Duplicate car key	$185-$220
Remote/Flip keys	$200-$300
Keyless entry device	$220-$320
Ignition repair	$195-$295
Key extraction	$95-$150
Ignition replacement	$250-$320
EWS/ECU re-flash	$400-$700




* Estimates above includes the technician coming out to you the parts and the labor.

Final price depends on:

• The state of the lock and the computer in the vehicle.
• The type of equipment that the technician need to use.
• The type of key that you would like to have.
• The chip configuration.

The tech will diagnose the vehicle and provide a price for you to approve before doing anything.




How long does it takes to make a key?

Our emergency mobile motor vehicle lock-smith are functional 24 hours a day throughout the week all year long. Ready to handle all your Land Rover keys and locks burdens. We usually arrive at customer location fast.




Our workshop truck is utterly arrayed with current diagnostic, cutting and programming appliances able to restore keys onsite. A key replacement process for a vehicle usually done same day.




We feel self-worth in maintaining a cost-effective cost and reliable services. Give us a call at for a FREE ESTIMATE and our Land Rover expert will arrive to your place ASAP. Okey DoKey Locksmith is always here to meet your needs in a professional way.
